Now, I’m the first to say, “You’ve got a $50,000 boat tied to the dock and you’re fretting about $200 in fuel? What’s up, doc?” But with that said, “Waste not, want not!” and this column is about that.
Some Basics
Would it be any surprise to know that heavier boats need more fuel at a given speed to move through or over the water? So, why lug around gear that you don’t need? Go through all your lockers and lazarettes and get rid of gear that’s sitting around gathering mildew. Store in it the garage, a dockside locker, or the garbage heap. Do you have an onboard water tank? I once had a 25-foot Chris-Craft with a 40-gallon water tank – which I kept full whether I was going out for the afternoon or an overnighter. At +8 pounds per gallon, this was like having a New York Giants lineman on my boat! Some of the bigger boats have 100-gallon tanks for showers – three linemen! Fill up the water tank where and when you are going to use it.
Name that Tune
Your propeller is the next most important item to tune. “Tune up my prop?” you say? Yes. If your prop (pitch) is too large for the boat, you are wasting energy. Wait – it came with the boat as original equipment. How can it be too large now? Simple – as the boat gets older (i.e., heavier), the prop’s “pitch,” i.e. how far the boat goes with one revolution of the prop, has to come in in order for the engine to still match the pitch and distance.
A ding in the prop (never hit the bottom, you say?) can take as much as 10% in fuel efficiency out of the powerplant. Think of it this way. You ask for 20 gallons and the fuel tender puts 18 in your tank, pours 2 gallons down the fuel storage sump and charges you for 20 gallons. Make sense to you, Bunky?
Bottom’s Up!
A fouled bottom is like dragging the anchor as you motor. It reduces hull “lubricity” versus the water and, if the hull is fouled, the running gear probably is too. There are plenty of eco-friendly bottom paints now, so keep the bottom clean and painted.
Speed Kills (Fuel Efficiency!)
Let’s stop review some maritime math. For vessels under sail, the longer the “wetted surface,” the faster the boat can go. This is why, in sailboat races, boats are assigned handicaps. In theory, the handicap eliminates any structural advantages that a 25-foot boat has over a 16-footer, so it’s then all about the crew. The formula for a boat’s “hull speed” (sometimes called the “displacement speed,” and soon you’ll understand why) is:
V = 1.34 x SQRT(LWL)
where SQRT means Square Root and LWL means length of the waterline in feet. V(velocity) conveniently comes out in knots.
So, the theoretical hull speed of the 25-foot sailboat is 6.7 knots and the 16-foot sailboat’s hull speed is 5.4 knots. In an interesting historical side note, this little fact caused a number of great clipper ships to mysteriously sink. How? Well, the captain throws on more sail to make the ship go faster. As you know, a ship’s form, viewed from bow looking aft, is to some extent a big, long “V” – the bottom of the “V” is in the water and the top, planked over, is the deck. The only way for the ship to respond to the increased power from the sails was for the “V” to dig deeper into the water so there was more wetted surface to service the power. More sail, more power. This drove the “V” deeper until the “V”, or the ship, drove herself under the water and sank.
But wait. I have a 25-foot boat and she goes considerably faster than 6.7 knots. How? She uses horsepower to defeat the physics of the “hull speed” equation – also known as the “displacement speed” equation. As our powerboats go faster, the “V” comes up OUT of the water – we convert from a displacement vessel to a “planing” vessel. But at 6.7 knots, I’m burning 2 gallons an hour. At 25 knots, I’m burning 10 times that but only going about 4 times as fast. It can get very complicated when we start talking about bow waves and stern waves interacting and the trim of the engine versus the boat’s waterline, etc. Suffice it to say this: You’ll use less fuel at 20 knots than at 25 knots and you’ll use less fuel at all speeds if you REDUCE your wetted surface (trim the bow up a bit – experiment at a fixed throttle setting to see what your speed-over-the-water does at a given setting) by using your trim tabs – and reducing the weight of the boat (back to the basics!) so the “V” doesn’t sit so deeply in the water naturally.
Lastly, install a fuel meter in your boat. If all our cars and boats had them (anybody in Washington, DC listening?), our national fuel consumption would improve overnight! Nothing slows a boat down from 25 knots to 15 knots faster than realizing you’re burning 20 gallons an hour ($100!) at 25 knots. ■
